AFCEN-RM-16-218-C

This methodological guide covers the drafting of Nuclear Particular Materials Assessments (NPMAs) for N2/N3 nuclear pressure equipment, as required in the RCC-M, section ZY 310 - ESR 4.2 - PMA of appendix ZY [5].

This guide includes:

• The definition of the scope for which the manufacturer must establish an NPMA,
• A proposal of a structured NPMA template that is adapted to materials procured according to the RCC-M code [5],
• The principles for the manufacturer’s use of the template,
• The definition of the type and level of justifications that the manufacturer must produce for preparing NPMAs,
• Proposed proof methods to justify compliance of the materials with the applicable ESR/RPR according to the directive [1] and the ESPN Order [4], including references to the PTANs, as necessary.

This guide is based on the justifications and analysis of the CLAP and COLEN sheets discussed in the criteria report [11].

The purpose of this guide is also to help notified bodies to assess the compliance of N2/N3 nuclear pressure equipment.

=========

[1] European directive (PED) 2014/68/EU of 15 May 2014
[4] French Order of 30 December 2015 relating to nuclear pressure equipment, amended by the Order of 03 September 2018
[5] AFCEN RCC-M Code (2016 edition) - Design and Construction Rules Applicable to the Mechanical Components of PWR Nuclear Islands
[11] AFCEN (2017), RM 17-308 A, Criteria Report - Preparing NPMAs for N2/N3 nuclear pressure equipment
